Fender SQ-AFF-JAG-3TS
A superb gateway into the time-honored Fender® family, the Squier® Affinity Series® Jaguar® delivers legendary design and quintessential tone for today’s aspiring guitar hero. This model features several player-friendly refinements such as a thin and lightweight body, a slim and comfortable “C”-shaped neck with short 24“ scale length, a vintage-style tremolo and floating bridge for superior tremolo action and sealed die-cast tuning machines with split shafts for smooth, accurate tuning and easy restringing. Loaded with two Squier single-coil pickups with 3-way switching for genre-defying sonic variety, this model is ready to accompany any player at any stage.
- Thin and lightweight body
- Floating bridge and vintage-style tremolo
- Slim and comfortable “C”-shaped neck profile
- Two Squier single-coil pickups
- Sealed die-cast tuning machines with split shafts
FEATURES
- Thin and lightweight body
- Floating bridge and vintage-style tremolo
- Slim and comfortable “C”-shaped neck profile
- Two Squier single-coil pickups
- Sealed die-cast tuning machines with split shafts
Feature |
Details |
General |
|
Series |
Affinity Series® |
Orientation |
Right-Hand |
Color |
3-Color Sunburst |
Body |
|
Body |
Poplar |
Body Finish |
Gloss Polyurethane |
Body Shape |
Jaguar® |
Body Material |
Poplar |
Neck |
|
Neck Material |
Maple |
Neck Finish |
Satin Urethane with Gloss Urethane Headstock Face |
Neck Shape |
“C” Shape |
Neck Construction |
Bolt-On |
Fingerboard Radius |
9.5” (241 mm) |
Fingerboard Material |
Indian Laurel |
Position Inlays |
Pearloid Dot |
Side Dots |
White |
Number of Frets |
22 |
Truss Rod |
Head Adjust |
String Nut |
Synthetic Bone |
Nut Width |
1.65” (41.91 mm) |
Nut Material |
Synthetic Bone |
Hardware |
|
Bridge |
Floating Bridge and Tailpiece |
Pickguard |
3-Ply Black |
Pickup Covers |
White |
Control Knobs |
Black Plastic |
Switch Tip |
White |
Hardware Finish |
Chrome |
Tuning Machines |
Sealed Die-Cast with Split Shafts |
String Trees |
Dual-Wing |
Strings |
Nickel Plated Steel (.009–.042 Gauges) |
Tremolo Arm |
Pop-In |
Neck Plate |
4-Bolt Squier® |
Strap Buttons |
Standard |
Electronics |
|
Bridge Pickup |
Ceramic Single-Coil |
Neck Pickup |
Ceramic Single-Coil |
Pickup Configuration |
SS |
Controls |
Master Volume, Master Tone |
Switching |
3-Position Blade: 1. Bridge Pickup 2. Bridge and Neck Pickups 3. Neck Pickup |
