Fender SQ-AFF-STRAT-JR-HSS-IBM
DESCRIPTION
- Reduced-size body and short 24“ scale length
- HSS pickup configuration
- 2-point tremolo bridge
- Slim and comfortable “C”-shaped neck profile
- Sealed die-cast tuning machines with split shafts
FEATURES
- Reduced-size body and short 24“ scale length
- HSS pickup configuration
- 2-point tremolo bridge
- Slim and comfortable “C”-shaped neck profile
- Sealed die-cast tuning machines with split shafts
|
Category |
Specification |
|
Body |
|
|
Body Material |
Poplar |
|
Body Finish |
Gloss Polyurethane |
|
Body Shape |
Stratocaster® |
|
Neck |
|
|
Neck Material |
Maple |
|
Neck Finish |
Satin Urethane with Gloss Urethane Headstock Face |
|
Neck Shape |
“C” Shape |
|
Neck Construction |
Bolt-On |
|
Fingerboard Radius |
9.5” (241 mm) |
|
Fingerboard Material |
Indian Laurel |
|
Position Inlays |
Pearloid Dot |
|
Side Dots |
White |
|
Number of Frets |
20 |
|
Truss Rod |
Head Adjust |
|
Truss Rod Nut |
4 mm Hex |
|
String Nut |
Synthetic Bone |
|
Nut Width |
1.650” (42 mm) |
|
Nut Material |
Synthetic Bone |
|
Hardware |
|
|
Bridge |
2-Point Synchronized Tremolo with Block Saddles |
|
Pickguard |
3-Ply White |
|
Pickup Covers |
White |
|
Control Knobs |
White Plastic |
|
Switch Tip |
White |
|
Hardware Finish |
Chrome |
|
Tuning Machines |
Sealed Die-Cast with Split Shafts |
|
String Trees |
Dual-Wing |
|
Strings |
Nickel Plated Steel (.009-.042 Gauges) |
|
Tremolo Arm |
Screw-In |
|
Neck Plate |
4-Bolt Squier® |
|
Strap Buttons |
Standard |
|
Electronics |
|
|
Bridge Pickup |
Ceramic Humbucker |
|
Middle Pickup |
Ceramic Single-Coil |
|
Neck Pickup |
Ceramic Single-Coil |
|
Pickup Configuration |
HSS |
|
Controls |
Master Volume, Master Tone |
|
Switching |
5-Position Blade:1. Bridge Pickup2. Bridge and Middle Pickup3. Middle Pickup4. Middle and Neck Pickup5. Neck Pickup |
